Description
|
Elliptical fuel tank trailer FTT124 |
||||
|
Dimension |
Length |
12000mm |
Volume |
45CBM |
|
|
Width |
2500mm |
Payload |
34000KG(40000L) |
|
|
Height |
3600mm |
GVW |
18000KG |
|
|
Carrying Liquid |
Gasoline / Diesel (Ensity: 0.85) |
Loading capacity |
Bottom loading |
|
|
Design Pressure |
0.02Mpa |
Design Temperature |
50℃ |
|
Tank body |
Tank body thickness |
Q345B steel 5mm, cylinder 6mm |
Compartment |
5 |
|
|
Manhole Cover |
API 500mm 2nos |
Seal End |
Steel 6.0mm/Q235B |
|
|
Ladder |
At rear of tank |
Pipeline |
DN80, 2% angle |
|
|
Fence at top of tank |
Made of tank |
Handrail at the top of tank |
1 |
|
Chasis |
Frame |
Q345B steel 5mm |
|
|
|
|
Axle |
13T FUWA/BPW 3nos |
Drum |
Hub piloted cast steel |
|
|
Suspension |
Mechanical suspension |
Leaf Spring |
10nos 90mmx13mm |
|
|
Tire |
12R22.5 12nos |
Wheel |
9.0-20 12nos |
|
|
Landing Gear |
JOST E100 |
Traction Pin |
JOST2”/3.5” |
|
Accessories |
Discharge Valve |
DN80 Fidlock valve 100mm API standard 1no |
Anti-static Electricity |
Copper sheet, cable, static conducting belt |
|
|
Emergency Valve |
Pneumatic bottom valve 1no |
Tank gauge |
1no |
|
|
Mudguard |
Closed type |
Fire Extinguisher |
4KG at both sides |
|
|
Charging system |
2” man hole; 2” check valve; 1.5 safe valve; 0.4Mpa gauge |
Quadratic blow |
1” diameter check valve |
|
|
Brake System |
WABCO valve, 6 double chamber |
Tool Box |
1 set |
|
|
Electrical |
24V 7 ways |
Lamp |
LED |
|
|
Spare Wheel Carrier |
2 |
Others |
|
|
Painting |
Sand blasted, anti-rust chassis surface is available with 1 layer, of anti-corrosive primer and 2 layers of top coats. |
|||
